FEATURES

• Pour-in-place installation for attachment to embedded rebar
• Features dual-layer jacketed web for abrasion resistance and plated alloy steel D-ring.
• For loop-over or choke-on installation to rebar during concrete pour
• Remove and dispose after temporary use in cured concrete
• Meets OSHA 1926.502 regulations

MATERIAL SPECIFICATIONS

• Webbing: Polyester; 5,000 lb min. static strength
• D-ring: Plated alloy steel; 5,000 lb min. static strength

PERFORMANCE SPECIFICATIONS

• Static Strength: 5,000 lb min.
• ANSI User Capacity: 130 to 310 lb max.
• OSHA User Capacity: 130 to 425 lb max.

AVAILABLE SIZES

Note: Check out the 4' Concrete Embed Anchor, 8' Concrete Embed Anchor, 6' Concrete Embed Anchor, 4' Concrete Embed Anchor with D-Ring 50/pack, and 3' Concrete Embed Anchor listings for all the available sizes.

DOWNLOADS

• Instruction Manual
• Declaration of Conformity
• Spec Sheet

COMPLIANT WITH:

OSHA 1926.502 and 1910.66
