Pelsue Permanent Davit System - DK4248 Mast (42"/48" Offset) + DSS-C2 Cylinder Core Mount

The DK4248 is Pelsue's longest-reach Davit mast in this lineu, 42" to 48" of offset, 48 lbs of structural aluminum, with the CP60 center post and EM01 elbow included. This configuration pairs it with the DSS-C2 Cylinder Core Mount (stainless steel), drilled into existing concrete or poured into fresh concrete and secured with grout or epoxy compatible with plant conditions. Setup takes about 5 minutes; the system is man-rated to 310 lbs.

This sleeve type, like all Pelsue permanent mount sleeves, offers:

• Always on site
• Provides greater offset reach
• Allows 360° pivot

Note: This combo includes the mast and mounting sleeve only. A hoist, Standard SRL, or 3-Way SRL (sold separately) completes the working system, along with its matching bracket (MB-PF1 for hoists, MB-FSB for Standard SRLs). The Davit System's universal bracket mounts one device, with an additional mounting location available for a second hoist or SRL if your application needs both.
